MARK4 HD 5" frame
Manufacturer: | |
Model: | GEP-Mark4HD5 |
Unit price: | 78.37 EUR/ |
|
|
Summary:
|
Description
The perfect match DJI FPV Air Unit
3D printing parts are fixed and protected
No propeller in the view
Full 3K Carbon Fiber Frame
Super lightweight Freestyle frame
Beautiful appearance design,durable in crashing
Quick maintenance Arms and replacement of equipment
25mm standoffs for better height and CG relation,Ample space for electronic installation
ALU6061 Srandoff New , Strengthen the hardness
There are 30.5*30.5mm and 20*20mm flight control holes , Stack can fit in the center or the rear.
High quality 3K twill carbon fiber plate, high precision CNC processing
YFS screw, 12.9 grade strength, non-slip teeth, anti-rust,Durable steel hardware
Recommended:
Flight Controller:RF/Kiss/F3/F4/F7
Motor: 22xx/23xx/24xx/25xx
ESC:30A-50A
Propeller:5inch
Lipo: 4S 1500mAh ~ 6S 1300mAh
FPV :DJI FPV Air Unit
Parameters
Dimensions (Length * Width * Height) | 138x176 mm |
Mounting pattern | 20x20/30,5x30,5 mm |
stílus | freestyle |
Weight | 121 g |
Váz formája | H |
Brand name:GEPRC | |
Item name:Mark 4-5 | |
Frame type:H type | |
Propeller | 5inch |
Motor to motor:225mm | |
Size:145*172mm | |
Weight:102g | |
Arms plate | 5mm |
Side plate | 2.5mm |
Top plate | 2.5mm |
Bottom plate | 2.5mm |
Protect plate | 2mm |
Package contents
2 x 2.5mm side plate
1 x 2.5mm top plate
1 x 2.5mm Bottom plate
2 x 2mm Bumpers plate
2 x 2mm Reinforce plate
1 x Lipo silicone pad
1x DJI FPV Air Unit fixed
1x Antenna Mount
1x RX Antenna Mount
